Termékparaméterek

•

  X3-GRD-350K-HV

  • PV INPUT



    Max. PV input power per MPPT	525 kWp
    MPPT voltage range	500 ~ 1500 V
    No. of MPP trackers / strings per MPP tracker	6 / 5
    Max. input current per MPPT	115 A




  • AC OUTPUT



    Rated output power	350 kW
    Rated AC voltage	3 / PE, 800 V




  • GENERAL



    Ingress protection	IP66
    Dimensions (W /H / D)	1225 x 825.5 x 369.1 mm
    Net Weight	< 130 kg
    Cooling concept	Smart air cooling




•

  X3-GRD-333K-HV

  • PV INPUT



    Max. PV input power per MPPT	499.5 kWp
    MPPT voltage range	500 ~ 1500 V
    No. of MPP trackers / strings per MPP tracker	6 / 5
    Max. input current per MPPT	115 A




  • AC OUTPUT



    Rated output power	333 kW
    Rated AC voltage	3 / PE, 800 V




  • GENERAL



    Ingress protection	IP66
    Dimensions (W /H / D)	1225 x 825.5 x 369.1 mm
    Net Weight	< 130 kg
    Cooling concept	Smart air cooling




•

  X3-GRD-320K-HV

  • PV INPUT



    Max. PV input power per MPPT	480 kWp
    MPPT voltage range	500 ~ 1500 V
    No. of MPP trackers / strings per MPP tracker	6 / 5
    Max. input current per MPPT	115 A




  • AC OUTPUT



    Rated output power	320 kW
    Rated AC voltage	3 / PE, 800 V




  • GENERAL



    Ingress protection	IP66
    Dimensions (W /H / D)	1225 x 825.5 x 369.1 mm
    Net Weight	< 130 kg
    Cooling concept	Smart air cooling




•

  X3-GRD-300K-HV

  • PV INPUT



    Max. PV input power per MPPT	450 kWp
    MPPT voltage range	500 ~ 1500 V
    No. of MPP trackers / strings per MPP tracker	6 / 5
    Max. input current per MPPT	115 A




  • AC OUTPUT



    Rated output power	300 kW
    Rated AC voltage	3 / PE, 800 V




  • GENERAL



    Ingress protection	IP66
    Dimensions (W /H / D)	1225 x 825.5 x 369.1 mm
    Net Weight	< 130 kg
    Cooling concept	Smart air cooling
